After you repair the Wheel Steering Motor, our product can be directly tested on the workbench to see if it works properly without the need to reinstall it in the car for repeated testing.
Operation:
ACC: Device ON/OFF
Power supply:12V 10A, we don't send with this cable.
Screen:Show work voltage or current of the tester.
Support to connect to other diagnostic scanner to check the real-time data for Wheel Steering Motor.
CAN Indicator LED:
Green LED: EPS provide CAN BUS.
Red LED: No CAN BUS from EPS.
PL118 EPS Model Support:
| For AUDI | Q4 SUV(F4B) | 2021-2025 |
| For AUDI | A3 Limousine(8YS) | 2020-2025 |
| For AUDI | A3 Sportback (8YA) | 2020-2025 |
| For SKODA | ENYAQiV SUV | 2020-2025 |
| For SEAT | LEON Sportstourer(KL8) | 2020-2025 |
| For VW | ID.3 | 2020-2025 |
| For VW | ID.4 | 2021-2025 |
| For VW | ID.5 | 2021-2025 |
| For VW | ID.6 | 2021-2025 |
| For VW | GOLF VIIIVariant(CG5) | 2020-2025 |
| For VW | CADDYV B5H | 2021-2025 |
Note:
1. Need to use with torque sensor, if your EPS without torque sensor, you need to buy one.
2. Additionally, during the steering testing process, it's advisable to avoid extending to the maximum limit to reduce the risk of losing EPS computer board data.
